MIDI-CI: Profile Details & Multi-Channel Negotiation

Hey music tech enthusiasts! Let's dive into the STR-MIDI2-019: Profile Details Inquiry for Multi-Channel Negotiation, a crucial specification for modern MIDI devices. This is all about how your fancy MIDI controllers and sound modules can talk to each other and figure out the best way to use multiple MIDI channels. This ensures your setups are flexible and compatible. Ready to get technical? Let’s break it down!

The Core Concept: Multi-Channel Profiles and Negotiation

What are Multi-Channel Profiles?

First off, what are we even talking about? Think of Multi-Channel Profiles as special MIDI configurations designed for complex instruments. For example, imagine a virtual guitar with six strings. It might use seven MIDI channels: one for the manager (think of it like the main control channel) and one for each of the six strings. Or, how about a drawbar organ with multiple manuals and pedals? These can also utilize multiple channels to manage their various components.

Why Negotiation is Key

Now, here’s the problem: not all devices are created equal. Some might handle all seven guitar channels, while others might only support four. That's where negotiation comes in. The idea is for your MIDI controller to ask the sound module, “Hey, how many channels can you handle for this guitar profile?” The sound module replies, and the two devices can then work together to find the best configuration. This is what the STR-MIDI2-019 specification is all about!

The Stakeholder's Need: Smooth Interoperability

The MIDI Controller Manufacturer's Perspective

Imagine you're a MIDI controller manufacturer. You want your device to work flawlessly with a wide range of sound modules. The goal is to provide optimal interoperability. This means that when a user plugs in their guitar controller, it just works, whether the sound module is a high-end synthesizer or an older device. You need a system where the controller can adapt to the sound module's capabilities. This is exactly what the Profile Details Inquiry helps achieve.

Adapting to Responder Capabilities

The specification allows the controller to request a certain number of channels (e.g., seven for a guitar), but it gracefully accepts fewer if that’s all the sound module can handle (e.g., four). This means the user still gets a functional setup, even if not every string is individually controllable. It's all about making the user experience seamless, regardless of the gear they have. That’s a win-win!

Acceptance Criteria: How It All Works

R1: Profile Details Inquiry Messages

Alright, let’s dig into the nitty-gritty. This part of the specification defines the messages used for the Profile Details Inquiry. It involves two crucial Sub-IDs within the MIDI-CI Universal SysEx messages:

  • Profile Details Inquiry (Sub-ID 0x28): The controller sends this to request information.
  • Reply to Profile Details Inquiry (Sub-ID 0x29): The sound module sends this back with the requested details.

It also specifies an Inquiry Target field. This field tells the sound module what information the controller is requesting. For example, to find out about the number of MIDI Channels, the Inquiry Target field is set to 0x00. The spec also includes handling the scenario where a Profile ID isn't supported, sending a NAK (Negative Acknowledgment) with a Status Code of 0x04.

R2: Number of Channels Negotiation Workflow

This is the heart of the negotiation process. Here’s a simplified breakdown of the five steps:

  1. Initiator Sends Inquiry: The MIDI controller (initiator) sends a Profile Details Inquiry with the Target set to 0x00 (Number of Channels).
  2. Responder Provides Details: The sound module (responder) replies with two crucial pieces of information:
    • Channels Currently In Use: This tells you how many channels are currently being used (0x00 0x00 if the profile is disabled).
    • Maximum Number of Channels: This is the maximum number of channels the sound module can handle.
  3. Initiator Sends Set Profile On: The controller sends a “Set Profile On” message, specifying the Number Channels Requested. This number must be less than or equal to the maximum the sound module reported.
  4. Responder Confirms Enable: The sound module replies, confirming the profile is enabled and includes the Number Channels Enabled, which is the actual number of channels allocated.
  5. Profile Enabled, Negotiation Complete: The controller now knows exactly how many channels are available and can configure itself accordingly. Bam!

This dance ensures that both devices agree on the configuration.

R3: Target Data Format (Number of Channels)

This section defines the format of the data that’s being exchanged. For the Number of Channels, the specification uses:

  • Inquiry Target Data Length: 0x04 0x00 (meaning 4 bytes of data).
  • Two-Byte Fields (LSB first): This is how the data for the number of channels is encoded.
    • Channels Currently In Use: The total number of channels being used (0x00 0x00 if the profile is disabled).
    • Maximum Number of Channels: The highest number of channels available.

It's crucial to understand this data structure to correctly interpret the information being sent back and forth.

R4: Registered vs. Profile-Specific Target Data

Things get a bit more advanced here. The spec distinguishes between two types of target data:

  • Registered Target Data: This is the format defined by the Common Rules specification, like the Number of Channels.
  • Profile-Specific Target Data: This is data defined within the specific Profile specification itself (e.g., data related to individual string tuning in a guitar profile).

The important takeaway is that Registered Target Data must specify whether a reply can be sent as a Notification (without an inquiry), however, replying to a target 0x00 (Number of Channels) can ONLY be done through the Inquiry-Reply workflow. No unexpected notifications allowed!

R5: Profile Details Usage Rules

This section outlines how the Profile Details Inquiry should be used. It emphasizes that this inquiry is crucial for Multi-Channel Profiles that don't have a fixed channel count. Furthermore, it allows for Profile-Specific Targets for optional or extended features. For each Profile, the target format and data need to be clearly defined in the Profile specification, so everyone knows what’s going on.

Dependencies and Impact Assessment

Dependencies

The STR-MIDI2-019 specification relies on two other key documents: the MIDI-CI Specification (M2-101-UM) v1.2 and STR-MIDI2-018 (MIDI-CI Profile Framework). This means it builds upon the existing MIDI-CI framework and utilizes the principles laid out in those specifications. Understanding these dependencies is important for understanding the full context of this specification.

Impact Assessment

The impact of this specification is significant. It affects:

  • Interfaces: It uses MIDI-CI Universal SysEx messages with specific Sub-IDs (0x28, 0x29).
  • Components: It involves a Profile Details Handler, Multi-Channel Negotiation, and a Target Data Parser.
  • Data Structures: It defines the use of an Inquiry Target (0x00 for Number of Channels), Target Data (4 bytes), and the fields for Number Channels Requested/Enabled.

This isn't just a small tweak; it reshapes how devices handle multi-channel profiles.

Additional Notes and Real-World Examples

Manager and Member Channels

In this context:

  • The Manager Channel is the lowest-numbered channel in a series, on the lowest-numbered group. It’s like the main control channel.
  • Member Channels are all the other active channels within the profile.

Use Case Examples

To make it super clear, here are some examples:

  • Guitar Profile: Requires 7 channels (6 strings + manager) but can negotiate down to 4 if the sound module can't handle all seven.
  • Drawbar Organ Profile: Needs 4 channels (Upper/Lower/Pedals + manager) but can negotiate to 2 if needed.
  • Banjo Profile: Requires 6 channels (5 strings + manager), and the number is fixed, so no negotiation is required.

Future Considerations

Keep an eye out, because future versions of this specification may define additional Registered Target Data types. This means more flexibility and even more ways for devices to work together harmoniously!

Conclusion: The Future of MIDI

So there you have it, folks! The STR-MIDI2-019 specification is a crucial piece of the puzzle for the future of MIDI. By allowing devices to negotiate the number of MIDI channels, it ensures compatibility, flexibility, and a smoother experience for musicians. This means less frustration, and more time making music! This is just one step in the ongoing evolution of MIDI, and it’s an exciting time to be involved in music technology. Keep an eye out for more updates and, as always, happy creating!
